Specificatie
|
Omschrijving
|
Model
|
Ksyrium Pro Carbon
|
Type
|
Tubeless
|
Naven
|
Front bearings : adjustable sealed cartridge bearings (QRM+), Rear bearings : auto adjust sealed cartridge bearings (QRM Auto)
Freewheel: Instant Drive 360
Front and rear bodies: aluminum
Axle material: aluminum
|
Velgen
|
ETRTO size: 622x19TC Road
Use with Mavic Tubeless Tape
Material: 3K carbon fibers
Height: 25mm
Brake track: carbon with iTgMAX technology
Drilling: traditional
Internal width: 19 mm
Valve hole diameter: 6.5 mm
Tyre: UST Tubeless and tubetype
|
Spaken
|
Shape: straight pull, aero, double butted
Count: front 18, rear 24
Nipples: aluminum, ABS
Material: steel
Lacing: front radial, rear Isopulse
|
Banden
|
Front and Rear Tread: 11 Storm single compound
Yksion Pro UST
UST Tubeless Ready
Dimension: 25-622 (700x25c)
Breaker: Polyamide, from bead to bead
Casing: 127 TPI
|
Gebruik
|
For a longer longevity of the wheel, Mavic recommends that the total weight supported by the wheels don't exceed 120kg, bike included
ASTM CATEGORY 1 : road only
Max. Pressure tubeless: 25mm 6 bars - 87 PSI, 28mm 5 bars - 70 PSI. Max pressure tubetype: 25mm 7 bars - 102 PSI, 28mm 6 bars - 87 PSI
Recommended tyre sizes: 25 to 32 mm
|
Compabiliteit
|
Rear axle: Quick Release only
Front axle: Quick Release only
Freewheel: Shimano/Sram, convertible to Campagnolo and XD-R with optional driver bodies
|
Gewicht
|
1445 gram
|
INCL
|
Tyre sealant syringe
Mavic tyre sealant (rear wheel)
Tubeless rim tape
BR601 Titanium quick releases
Multifonction adjustment wrench
Carbon brake pads
UST valve and accessories
User guide
|
